How to use Type converter in XAML ( Windows Applications )?

We're going to discuss about Automatic Type converters in XAML.

Whenever you make some control in XAML you set its properties. For example in following screen shot we are making a button in XAML and setting its properties like:

Name

Horizontal Alignment

Margin

Background

Vertical Alignment

Horizontal Alignment

Background Color etc , you are shown a list of given option through Intellisense like below:

So you have limited options as shown in above screenshot. you've to select 1 position from 4 given options . These options are infect enums.

have you ever noticed that when you type in for setting the properties like ,

Now I'm going to show you the alternate way to set properties using C# syntax. To make a button from C# write following code in Page Load Event in program.

When you make a control from C# code. You've to set all of its properties in code. In this case we've set its

HorizontalAlignment
Background properties

You selected the background color and Horizontal Alignment from a strongly typed enumeration for the button. So the question is ! How these properties are mapped to strongly typed enumeration, when you type a string which is "left" in the case of alignment property and "Red" in case of color selection.

Answer is ! XAML parser does this job.

XAML parser convert string value into a strongly typed version of that value. So when you set the properties like < horizontalAllignment = "Left" > , the string "Left" will be mapped to the strongly typed enum by the XAML parser.

How to use Image Brush in Silverlight and Windows phone applications?

This article demonstrates how to create and use an image brush in Silverlight using XAML and C#.

Image Brush

An image brush paints an area with an image. The ImageSource property represents the image to be used during the painting by an image brush. The ImageBrush object represents an image brush.

Creating an Image Brush

The ImageBrush element in XAML creates an image brush. The ImageSource property of the ImageBrush represents the image used in the painting process.

The following code snippet creates an image brush and sets the ImageSource property to an image.

We can fill a shape with an image brush by setting a shape's Fill property to the image brush. The code snippet in Listing 1 creates a rectangle shape sets the Fill property to an ImageBrush.

<Rectangle

Width="200"

Height="100"

Stroke="Black"

StrokeThickness="4">

<Rectangle.Fill>

</Rectangle.Fill>

</Rectangle>

Listing 1

The output looks like Figure 1.

Figure 1

The CreateAnImageBrush method listed in Listing 2 draws same rectangle with an image brush in Figure 1 dynamically.

/// <summary>

/// Fills a rectangle with an ImageBrush

/// </summary>

public void CreateAnImageBrush()

{

// Create a Rectangle

Rectangle blueRectangle = new Rectangle();

blueRectangle.Height = 100;

blueRectangle.Width = 200;

// Create an ImageBrush

ImageBrush imgBrush = new ImageBrush();

imgBrush.ImageSource =

new BitmapImage(new Uri(@"Dock.jpg", UriKind.Relative));

// Fill rectangle with an ImageBrush

blueRectangle.Fill = imgBrush;

// Add Rectangle to the Grid.

LayoutRoot.Children.Add(blueRectangle);

}

Listing 2

Summary

In this article, we saw how to create and use an image brush in Silverlight using XAML and C#.

how to use XAML GroupBox in WPF and Windows phone application?

The GroupBox element in XAML is used to add a header to an area and within that area you can place controls. By default, a GroupBox can have one child but multiple child controls can be added by placing a container control on a GroupBox such as a Grid or StackPanel.

How to create a GroupBox in WPF and Windows phone application,.

The GroupBox element in XAML represents a GroupBox control. The following code snippet creates a GroupBox control and sets its background and font. The code also sets the header using GroupBox.Header.

<Window x:Class="GroupBoxSample.Window1"
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
Title="Window1" Height="300" Width="300">
<Grid>
<GroupBox Margin="10,10,10,10" FontSize="16" FontWeight="Bold"
Background="LightGray">
<GroupBox.Header>
Mindcracker Network
</GroupBox.Header>
<TextBlock FontSize="12" FontWeight="Regular">
This is a group box control content.
</TextBlock>
</GroupBox>
</Grid>
</Window>

The output looks like this.

How to create and use Calendar in XAML and windows phone application Part-3?

Calendar Events

Besides the normal control events, the Calendar control has three events calendar related events. These events are the DisplayDateChanged, DisplayModeChanged and SelectedDatesChanged. The DisplayDateChanged event is fired where the DisplayDate property is changed. The DisplayModeChanged event is fired when the DisplayMode property is changed. The SelectedDatesChanged event is fired when the SelectedDate or SelectedDates properties are changed. The following code snippet sets these three events attributes.

The code behind for these events look as in Listing 4.

private void MonthlyCalendar_SelectedDatesChanged(object sender,
SelectionChangedEventArgs e)
{
}
private void MonthlyCalendar_DisplayDateChanged(object sender,
CalendarDateChangedEventArgs e)
{
}
private void MonthlyCalendar_DisplayModeChanged(object sender,
CalendarModeChangedEventArgs e)
{
}

Listing 4

Normally, on a date selection, you may want to capture that event and know what the current selected date is. Now how about we add a TextBox control to the page and on the date selection, we will set the text of the TextBox to the currently selected date.

We add the following code to the XAML just below the Calendar control. <TextBox Width="200" Height="30"
VerticalAlignment="Bottom"
HorizontalAlignment="Left"
Margin="10,10,10,10"
x:Name="SelectedDateTextBox">
</TextBox>

On the SelectedDateChanged event handler, we set the TextBox.Text property to the SelectedDate property of the Calendar control as you can see from the code in Listing 5.

private void MonthlyCalendar_SelectedDatesChanged(object sender,
SelectionChangedEventArgs e)
{
SelectedDateTextBox.Text = MonthlyCalendar.SelectedDate.ToString();
}

Listing 5

Now when you run the application, you will see the output that looks as in Figure 10. When you select a date in the Calendar, it will be displayed in the TextBox.

Figure 10

Formatting a Calendar

How about we create a Calendar control with a border formatting, background and foreground of the Calendar?

The BorderBrush property of the Calendar sets a brush to draw the border of a Calendar. You may use any brush to fill the border. The following code snippet uses a linear gradient brush to draw the border with a combination of the colors Red and Blue.

<Calendar.BorderBrush>
<LinearGradientBrush StartPoint="0,0" EndPoint="1,1" >
<GradientStop Color="Blue" Offset="0" />
<GradientStop Color="Red" Offset="1.0" />
</LinearGradientBrush>
</Calendar.BorderBrush>

The Background and Foreground properties of the Calendar set the background and foreground colors of a Calendar. You may use any brush to fill the border. The following code snippet uses linear gradient brushes to draw the background and foreground of a Calendar.

<Calendar.Background>
<LinearGradientBrush StartPoint="0,0" EndPoint="1,1" >
<GradientStop Color="Blue" Offset="0.1" />
<GradientStop Color="Orange" Offset="0.25" />
<GradientStop Color="Green" Offset="0.75" />
<GradientStop Color="Red" Offset="1.0" />
</LinearGradientBrush>
</Calendar.Background>
<Calendar.Foreground>
<LinearGradientBrush StartPoint="0,0" EndPoint="1,1" >
<GradientStop Color="Black" Offset="0.25" />
<GradientStop Color="Green" Offset="1.0" />
</LinearGradientBrush>
</Calendar.Foreground>

The new Calendar looks as in Figure 11.

Figure 11

Setting Image as Background of a Calendar

To set an image as the background of a Calendar, we can set an image as the Background of the Calendar. The following code snippet sets the background of a Calendar to an image. The code also sets the opacity of the image.

<Calendar.Background>
<ImageBrush ImageSource="Garden.jpg" Opacity="0.3"/>
</Calendar.Background>

The new output looks as in Figure 12.

Figure 12

Creating a Calendar Dynamically

The code listed in Listing 6 creates a Calendar control programmatically. First, it creates a Calendar object and sets its DisplayMode and SelectedMode and other properties and later the Calendar is added to the LayoutRoot.

private void CreateDynamicCalendar()
{
Calendar MonthlyCalendar = new Calendar();
MonthlyCalendar.Name = "MonthlyCalendar";
MonthlyCalendar.Width = 300;
MonthlyCalendar.Height = 400;
MonthlyCalendar.Background = Brushes.LightBlue;
MonthlyCalendar.DisplayMode = CalendarMode.Month;
MonthlyCalendar.SelectionMode = CalendarSelectionMode.SingleRange;
MonthlyCalendar.DisplayDateStart = new DateTime(2010, 3, 1);
MonthlyCalendar.DisplayDateEnd = new DateTime(2010, 3, 31);
MonthlyCalendar.SelectedDates.Add(new DateTime(2010, 3, 5));
MonthlyCalendar.SelectedDates.Add(new DateTime(2010, 3, 15));
MonthlyCalendar.SelectedDates.Add(new DateTime(2010, 3, 25));
MonthlyCalendar.FirstDayOfWeek = DayOfWeek.Monday;
MonthlyCalendar.IsTodayHighlighted = true;
LayoutRoot.Children.Add(MonthlyCalendar);
}

Listing 6

Summary

In this article, I discussed the calendar control using XAML and C#. We also saw how to set display modes, selection modes, blackout dates, selected dates, border, background and foreground properties. After that, we saw you to set an image as the background of a Calendar. In the end of this article, we saw how to create a Calendar dynamically.

How to create and use Calendar in XAML and windows phone application Part-2?

The following code snippet adds blackout dates to a Calendar.

<Calendar.BlackoutDates>
<CalendarDateRange Start="3/1/2010" End="3/7/2010"/>
<CalendarDateRange Start="3/8/2010" End="3/8/2010"/>
<CalendarDateRange Start="3/15/2010" End="3/15/2010"/>
<CalendarDateRange Start="3/22/2010" End="3/22/2010"/>
<CalendarDateRange Start="3/29/2010" End="3/29/2010"/>
</Calendar.BlackoutDates>

We can do this by adding the code listed in Listing 2. As you can see from Listing 3, the BlackoutDates.Add method takes a CalendarDateRange object, that is a collection of two DateTime objects. The first date is the start date of the range and the second date is the end date of the date range.

private void SetBlackOutDates()
{
MonthlyCalendar.BlackoutDates.Add(new CalendarDateRange(
new DateTime(2010, 3, 1),
new DateTime(2010, 3, 7)
));
MonthlyCalendar.BlackoutDates.Add(new CalendarDateRange(
new DateTime(2010, 3, 8),
new DateTime(2010, 3, 8)
));
MonthlyCalendar.BlackoutDates.Add(new CalendarDateRange(
new DateTime(2010, 3, 15),
new DateTime(2010, 3, 15)
));
MonthlyCalendar.BlackoutDates.Add(new CalendarDateRange(
new DateTime(2010, 3, 22),
new DateTime(2010, 3, 22)
));
MonthlyCalendar.BlackoutDates.Add(new CalendarDateRange(
new DateTime(2010, 3, 29),
new DateTime(2010, 3, 29)
));
}

Listing 2

DisplayDateStart and DisplayDateEnd

The Calendar control allows you to set the start and end display dates using the DisplayDateStart and DisplayDateEnd properties. If you see Figure 5 in the previous section, you may notice the March 2010 month calendar display starts with the March 01, 2010 date. But now, what if you want to display the dates for only the month of March 2010? We can use the DisplayStartDate and DisplayEndDate properties to control the start and end dates of a month.

DisplayDate property represents the current date to display.

The following code snippet sets the DisplayDate, DisplayDateStart and DisplayDateEnd attributes of the Calendar element in XAML.

The code listed in Listing 3 makes sure the start date is March 01, 2010 and end date is March 31, 2010. The current selected date is March 05.

private void SetDisplayDates()
{
MonthlyCalendar.DisplayDate = new DateTime(2010, 3, 5);
MonthlyCalendar.DisplayDateStart = new DateTime(2010, 3, 1);
MonthlyCalendar.DisplayDateEnd = new DateTime(2010, 3, 31);
}

Listing 3

The new calendar looks as in Figure 6.

Figure 6

FirstDayOfWeek and IsTodayHighlighted

By default, Sunday is the first day of the week. If you would like to change it, you use the FirstDayOfWeek property. The IsTodayHightlighted property is used to highlight today.

The following code snippet sets the FirstDayOfWeek to Tuesday and makes today highlighted.

The following code snippet sets the FirstDayOfWeek to Tuesday and makes today highlighted in WPF.

MonthlyCalendar.FirstDayOfWeek = DayOfWeek.Tuesday;
MonthlyCalendar.IsTodayHighlighted = true;

The new calendar looks as in Figure 7, where you can see the start day of the week is Tuesday.

Figure 7

Selected Date and Selected Dates

The SelectedDate property represents the current selected date. If multiple date selection is true then the SelectedDates property represents all the selected dates in a Calendar. The following code snippet sets the SelectedDates in XAML at design-time.

The selected dates in a Calendar looks as in Figure 8 where you can see March 5th, 15th and 25th have a light blue background and represents the selected dates.

Figure 8

The following code snippet sets the SelectedDates property in WPF at run-time.

private void AddSelectedDates()
{
MonthlyCalendar.SelectedDates.Add(new DateTime(2010, 3, 5));
MonthlyCalendar.SelectedDates.Add(new DateTime(2010, 3, 15));
MonthlyCalendar.SelectedDates.Add(new DateTime(2010, 3, 25));
}

Note: If you have set the selected dates to any of the blackout dates, you will see the parser in XAML will throw an error as in Figure 9.

Figure 9

How to create and use Calendar in XAML and windows phone application Part-1?

A calendar control is used to create a visual calendar that lets users pick a date and fire an event on the selection of the date. This article demonstrates how to create and use a calendar control using XAML and C# in WPF.

Creating a Calendar

The Calendar element represents a calendar control in XAML as in the following:

<Calendar/>

The Calendar control is defined in the System.Windows.Controls namespace. When you drag and drop a Calendar control from the Toolbox to the page, the XAML code will look like the following code where you can see a Calendar XAML element has been added within the Grid element and its Width, Height, Name and VerticalAlignment and HorizontalAlignment attributes are set.

<Grid>
<Calendar Height="170" HorizontalAlignment="Left" Margin="58,32,0,0"
Name="calendar1" VerticalAlignment="Top" Width="180" />
</Grid>

The default view of the Calendar control looks as in Figure 1.

Figure 1

The Width and Height attributes of the Calendar element represent the width and the height of a Calendar. The Content attribute represents the text of a Calendar. The Name attribute represents the name of the control, that is a unique identifier of a control.

The code snippet in Listing 1 creates a Calendar control and sets the name, height and width properties of a Calendar control.

<Calendar Name=" MonthlyCalendar" Height="30" Width="100" >
</Calendar>

Listing 1

Display Modes

The DisplayMode property of the Calendar class represents the format of the display of a Calendar, that can be a month, year, or decade. Month is the default mode. Setting the DisplayMode to Year and Decade generates Figure 2 and Figure 3 respectively.

Figure 2

Figure 3

The Month view that is also the default view looks as in Figure 4.

Figure 4

If you use an example of the Decade and click on the year 2008 in Figure 3, you will get another Calendar format with all the months in the year 2008 and if you click on any month, you will eventually get the month view of the Calendar.

The following code snippet sets the DisplayMode property to Decade.

<Calendar DisplayMode="Decade">
</Calendar>

Selection Modes and Selection Dates

The SelectedDate property represents the currently selected date. If multiple dates selection is true, the SelectedDates property represents a collection of currently selected dates.

The SelectionMode of type CalendarSelectionMode enumeration represents the selection mode of calendar. Table 1 describes the CalendarSelectionMode enumeration and its members.

CalendarSelectionMode	Description
None	No selections are allowed.
SingleDate	Only a single date can be selected, either by setting SelectedDate or the first value in SelectedDates. AddRange cannot be used.
SingleRange	A single range of dates can be selected. Setting SelectedDate, adding a date individually to SelectedDates, or using AddRange will clear all previous values from SelectedDates.
MultipleRange	Multiple non-contiguous ranges of dates can be selected. Adding a date individually to SelectedDates or using AddRange will not clear SelectedDates. Setting SelectedDate will still clear SelectedDates, but additional dates or range can then be added. Adding a range that includes some dates that are already selected or overlaps with another range results in the union of the ranges and does not cause an exception.

The following code snippet sets the SelectionMode property to a single range.

<Calendar SelectionMode="SingleRange">
</Calendar>

BlackoutDates

The BlackoutDates property of the Calendar class represents a collection of dates that are not available for selection. All non-selection dates are marked by a cross. For example, say in the month of March of the year 2010, we would like to block the dates from Jan 1st to Jan 7th and then all Sundays and the final calendar should look as in Figure 5.

Figure 5

Part 2 Continuous..

How to use a XAML RichTextBox in WPF and windows phone application?

Introduction

The RichTextBox control allows you to view and edit text, paragraph, images, tables and other rich text format contents.

The RichTextBox tag represents a RichTextBox control in XAML.

The Width and Height properties represent the width and the height of a RichTextBox. The Name property represents the name of the control, that is a unique identifier of a control. The Margin property tells the location of a RichTextBox on the parent control. The HorizontalAlignment andVerticalAlignment properties are used to set horizontal and vertical alignments.

The following code snippet sets the name, height and width of a RichTextBox control. The code also sets the horizontal alignment to left and the vertical alignment to top.

<RichTextBox Margin="10,10,0,13" Name="RichTextBox1" HorizontalAlignment="Left"

VerticalAlignment="Top" Width="500" Height="300" />

Displaying and Edit Text

A RichTextBox control hosts a collection of RichTextBoxItem. The following code snippet adds items to a RichTextBox control.

<RichTextBox Margin="10,10,0,13" Name="RichTextBox1" HorizontalAlignment="Left"
VerticalAlignment="Top" Width="500" Height="300">
<FlowDocument>
<Paragraph>
I am a flow document. Would you like to edit me?
<Bold>Go ahead.</Bold>
</Paragraph>

<Paragraph Foreground="Blue">
I am blue I am blue I am blue.
</Paragraph>
</FlowDocument>
</RichTextBox>

The preceding code generates Figure 1 where you can begin editing text right away.

RichTextBox with editable text

Creating and Using RichTectBox Dynamically

In the previous section, we saw how to create and use a RichTextBox in XAML. WPF provides the RichTextBox class that represents a RichTextBox control. In this section, we will see how to use this class to create and use a RichTextBox control dynamically.

The code listed in Listing 1 creates a FlowDocument, adds a paragraph to the flow document and sets the Document property of the RichTextBox to FlowDocument.

private void CreateAndLoadRichTextBox()
{
// Create a FlowDocument
FlowDocument mcFlowDoc = new FlowDocument();

// Create a paragraph with text
Paragraph para = new Paragraph();
para.Inlines.Add(new Run("I am a flow document. Would you like to edit me? "));
para.Inlines.Add(new Bold(new Run("Go ahead.")));

// Add the paragraph to blocks of paragraph
mcFlowDoc.Blocks.Add(para);

// Create RichTextBox, set its hegith and width
RichTextBox mcRTB = new RichTextBox();
mcRTB.Width = 560;
mcRTB.Height = 280;

// Set contents
mcRTB.Document = mcFlowDoc;

// Add RichTextbox to the container
ContainerPanel.Children.Add(mcRTB);
}

Listing 1.

The output of Listing 1 generates Figure 2.

Listing 1 doc

Enable Spelling Check

A RichTextBox control comes with spell check functionality out-of-the-box. By setting theSpellCheck.IsEnabled property to true enables spell checking in a RichTextBox.

SpellCheck.IsEnabled="True"

You can set this in code as follows:

mcRTB.SpellCheck.IsEnabled = true;

Now if you type some text, the wrong word would be underlined with the Red color. See in Figure 3.

RichTextBox with Spell Check Enabled

Loading a Document in RichTextBox
We can use the RichTextBox.Items.Remove or RichTextBox.Items.RemoveAt methods to delete an item from the collection of items in the RichTextBox. The RemoveAt method takes the index of the item in the collection.
Now, we modify our application and add a new button called Delete Item. The XAML code for this button looks as in the following:

private void LoadTextDocument(string fileName)
{
TextRange range;
System.IO.FileStream fStream;
if (System.IO.File.Exists(fileName))
{
range = new TextRange(RichTextBox1.Document.ContentStart, RichTextBox1.Document.ContentEnd);
fStream = new System.IO.FileStream(fileName, System.IO.FileMode.OpenOrCreate);
range.Load(fStream, System.Windows.DataFormats.Text );
fStream.Close();
}
}

How to use TreeView in XAML and Windows phone application Part 6?

PART 5: Continues

To bind an XmlDataProvider, we set the Source property inside the ItemsSource of a TreeView to the x:Keyof XmlDataProvider and the code in the code is used to filter the data. In the TreeView.ItemTempate, we use the Binding property.

<TreeView.ItemsSource>
<Binding Source="{StaticResource BooksData}"
XPath="*[@Category='Programming'] "/>
</TreeView.ItemsSource>
<TreeView.ItemTemplate>
<DataTemplate>
<StackPanel Orientation="Horizontal">
<TextBlock Text="Title: " FontWeight="Bold"/>
<TextBlock Foreground="Green" >
<TextBlock.Text>
<Binding XPath="Title"/>
</TextBlock.Text>
</TextBlock>
</StackPanel>
</DataTemplate>
</TreeView.ItemTemplate>
</TreeView>

The output of the preceding code looks as in the following.

xml data binding
Figure 11

The last data binding type we will see is how to provide data exchange between a TreeView and other controls using data binding in WPF.

We will create an application that looks as in the following. I have a TreeView with a list of colors, aTextBox and a Canvas. When we pick a color from the TreeView, the text of the TextBox and color of the Canvas changes dynamically to the color selected in the TreeView. This is possible to do all in XAMLwithout writing a single line of code in the code behind file.

Figure 12.

The XAML code of the page looks as in the following:

<StackPanel Orientation="Vertical">
<TextBlock Margin="10,10,10,10" FontWeight="Bold">
Pick a color from below list
</TextBlock>
<TreeView Name="mcTreeView" Height="100" Width="100"
Margin="10,10,0,0" HorizontalAlignment="Left" >
<TreeViewItem>Orange</TreeViewItem>
<TreeViewItem>Green</TreeViewItem>
<TreeViewItem>Blue</TreeViewItem>
<TreeViewItem>Gray</TreeViewItem>
<TreeViewItem>LightGray</TreeViewItem>
<TreeViewItem>Red</TreeViewItem>
</TreeView>
<TextBox Height="23" Name="textBox1" Width="120" Margin="10,10,0,0" HorizontalAlignment="Left" >
<TextBox.Text>
<Binding ElementName="mcTreeView" Path="SelectedItem.Content"/>
</TextBox.Text>
</TextBox>
<Canvas Margin="10,10,0,0" Height="200" Width="200" HorizontalAlignment="Left" >
<Canvas.Background>
<Binding ElementName="mcTreeView" Path="SelectedItem.Content"/>
</Canvas.Background>
</Canvas>
</StackPanel>

If you look at the TextBox XAML code, you will see the Binding within the TextBox.Text property that sets the binding from the TextBox to another control. Another control ID is ElementName and another control's property is Path. So in the following code, we are setting the SelectedItem.Content property of theTreeView to the TextBox.Text property.

<TextBox.Text>
<Binding ElementName="mcTreeView" Path="SelectedItem.Content"/>
</TextBox.Text>

The same applies to the Canvas.Background property, where we set it to the SelectedItem.Content of theTreeView. Now, every time you select an item in the TreeView, the TextBox.Text and Canvas.Backgroundproperties are set to the selected item in the TreeView.

<Canvas.Background>
<Binding ElementName="mcTreeView" Path="SelectedItem.Content"/>
</Canvas.Background>

Summary

In this article, I exlained how to create and use a TreeView control available in WPF. We saw how to add items to a TreeView, change item properties, add images and add check boxes. In the end of this article, we saw how data binding works for a TreeView and how to bind a TreeView with data coming from objects, a database and other controls.

How to use Type converter in XAML ( Windows Applications )?

Your comment on this post:

Related Articles
